Swashdrive
Whip - Invented & developed by Craig Wyeth, Australia
IN-STOCK -- Order Today because Supplies are limited.
|
Swashdrive
WHIP Slider adjusts from Hard to Soft hitting On-the-Fly. Same powerful motor as G7. Robust heavy duty construction. |
Craig Wyeth |
|
Slider moves in
1/2 - Step Increments
One Slider is installed, |
Price does not include cords, tubes or needles. |
The New RCA Version accommodates both RCA and Spring Clip Cord.
 |
 |
|
Swashdrive G7 Kit |
Swashdrive WHIP Kit Includes: The WHIP Polyamide Swashdrive, World Class Instek Power Supply, Combo Foot Switch Clip Cord or RCA Plug Tools, 1 each Hard and Soft Clips Clip Cord Kit #4AW111 RCA Jack Kit #4AW112 Buy the Kit and Save $684.95 |
RoHS Compliant
Voltage: 1.0 ~ 12 Volts
Amps: 0.08 ~ 0.35 Amps
- Speed: Cycles Per Second
- at 6.0 Volts - 50 CPS
- at 9.0 Volts - 100 CPS
- at 12 Volts - 150 CPS
Motor: 4.5 Watt
Custom Design
Swiss Maxon Motor
the motor has a life expectancy
of approx. 20,000 hours.
Power supplies
The Gen 7 and Whip Swashdrives will run on almost any power supply, but we strongly recommend the use of a quality bridge rectified Dual lab Instek, for the clean DC. Cheap single knob supplies with heaps of ripple & noise will reduce motor life somewhat.
Tested & Endorsed power
supplies for this machine.
Genuine GW Instek lab
Isotech lab (Model IPS303DD,
RS Components
part # 3256004)
The power supply should have no more than
Ripple & Noise ≥1.0mVrms ( 5Hz~1MHz )
(rating current <3A )
Tested and endorsed:
Genuine GW Instek, Isotech Lab
Swash
Gen VI:
- SET Volts to ZERO Volts
- SET Amps at FULL AMPS (Clockwise)
- Use Voltage knob to increase speed.
This is important on START-UP to deliver full amps
and then
settle to what the machine draws at desired voltage.
Swashdrive Whip:
6 to 9 Volts, producing 50 - 100 CPS
- SET Volts to ZERO
- SET Amps at FULL AMPS (Clockwise)
- Use Voltage knob to increase speed to 6 - 9 Volts.
The G7 Swashplate
The swashplate mechanism that drives the needle action is a very efficient means to convert the rotational motion of the electric motor to the reciprocating motion of the needle producing an approximate advantage of 15:1.
The swashplate delivers a sine wave motion - constant needle velocity - throughout the cycle producing a smooth non-stopping continuous motion as compared to the stop and start of conventional crank, cam (2-dimension) and coils. Only the swashplate can make use of all 3-dimension axes to create the natural fluid cyclic reciprocating action that produces a constant "brush-like" artistry feel experienced by fine art painting.
A small precision bearing has been added in the anvil
area to remove
the "rock-over" that was so hard on grommets
and nipples.
The Anvil area is now part of the C shape pivot clip.
Included are 4 replacement "C-Clips" with every machine.
Looking down at the Swash from above:
The motor will run in either direction
by Craig Wyeth says it likes CLOCKWISE direction.
RCA type connector wiring:
Positive (+) (Red wire) connected to center terminal
Negative (-) (Black wire) connected to
outer shield
Binding Posts for Spring type CLIP CORD
connector wiring:
Positive (+) (Red wire) connected to Top Post
Negative (-) (Black wire) connected to Bottom Post
If your Gen 6 is not running switch the clip cord around.
From www.swashdrive.com.au
Warranty
Swashdrive Tattoo machines have a Six month warranty from date of purchase. To which Swashdrive Developments will repair any manufacturing fault of the machine free of charge. However disassembly of electric motor from the main machine frame, or excess voltage from single knob power supplies wrecking electric motor will invalidate warranty. Proof of date of purchase must be provided for a warranty claim.
Disclaimer
Swashdrive Developments warrantees the manufacturing quality of Swashdrive Tattoo Machines. But under no circumstances is Swashdrive Developments in any way liable for any injury, infection or quality of any tattoo or of any person that a Swashdrive Tattoo machine is used on. That is the sole responsibility & liability of the Artist / Owner of a Swashdrive Tattoo machine.
We apologize to real tattoo people looking for detailed technical info on the Swashdrive.
We had to remove a lot of content from www.swashdrive.com.au because PARASITE SUPPLIERS were using the Tech Help info to make illegal copies both of technology and the Copyrighted "look" of our machines.
There is a GOLD COLOR KNOCKOFF of an earlier Swashdrive, a Black knockoff and a new knockoff of the G6.
Don't be fooled by parasites who steal and copy other peoples hard work and have no heart for tattoo.
The Swashdrive is a high tech device with quality components!
